THE PICOTE MILLER RANGE
THE POWER BEHIND PICOTE TOOLS
Picote’s Millers are versatile multi-use machines, and the power source for Picote’s range of tools.
Originally designed and developed over many years on Picote worksites across Finland, they are now truly global machines, used on thousands of worksites worldwide.
Every Picote Miller is designed to tackle a variety of challenging jobs. All Picote Millers offer high-speed cleaning options as standard.
Picote Millers are designed with safety and efficiency in mind, with a comprehensive range of tools for small diameter drain renovation from 1 ¼”-12″ pipes.
Every Picote Miller has a safety clutch as well as specialized outer casing covering the shaft making it safe for the user to hold.
PICOTE MINI CLEANER
OVERVIEW
The Mini Cleaner provides plumbers with a high-speed option for cleaning, descaling and blockage removal in various types of pipe.
This new innovation provides efficient high-speed cleaning with a focus on operator safety and high-end performance. The Mini Cleaner comes with a Safety Clutch fitted as standard. It is also equipped with specially produced, highly flexible performance outer casing for the shaft which is durable to abrasion and chemically resistant even with a high continuous service temperature.
Features include:
- Perfect for plumbers!
- High-speed drain cleaning option with a pipe cleaning tool range for various types of pipe for cleaning, descaling & blockage removal
- Suitable for small size pipes (DN32-DN75) with multiple 90 degree bends
- Efficient high-speed cleaning with focus on operator safety
- Proven high-end performance
- Safety Clutch fitted as standard
- 230v/10amp machine as standard
PICOTE MINI MILLER
OVERVIEW
The Mini Miller is equipped with specially produced, highly flexible performance outer casing for the shaft, which is durable to abrasion and chemically resistant even with a high continuous service temperature..
Use Picote’s new Special Drill Heads (sold separately) as cutters for your Mini Miller.
The specialty casing allows drain cleaning & reinstatements even through tight DN50 /2” traps.
- High speed drain cleaning
- Blockage removal
- Fast reinstatements through DN50, DN70 & DN100/2”, 3” & 4” P-Traps
Features include:
- 17m / 55ft of 8mm / ⅓” shaft with thick outer casing.
- Suitable for drain cleaning DN50 – 100 / 2″ – 4″ pipes.
- Use with DN50 & DN70 / 2″ & 3″ Smart Cutters & Twisters.
- Powers the Picote Coating System.
- Weighs 32kg / 71 lb
- 600 – 3000rpm, 1200w output.
- Lightweight aluminum frame.
- Perfect for working inside buildings.
Mini Miller +C / Mini Cleaner +C
Millers with integrated cameras
The Picote Mini Miller +C and Mini Cleaner +C units feature an integrated 30m colour camera that makes viewing of cleaning and cutting jobs easier and helps to make Picote Brush Coating setup even simpler.
With options for self-levelling and 512hz sonde.
Battery powered Mini Miller / Mini Cleaner
The Mini Miller and Mini Cleaner are now both available in new cordless, battery operated models! With the same features as their original corded versions, now even easier to transport and operate regardless of power outlet location or availability.
Operation time:
- Up to 3 Hours with Standard Battery
- Up to 4 Hours with High output Battery
Mini Miller +C / Mini Cleaner +C
Millers with integrated cameras
The Picote Mini Miller +C and Mini Cleaner +C units feature an integrated 30m colour camera that makes viewing of cleaning and cutting jobs easier and helps to make Picote Brush Coating setup even simpler.
With options for self-levelling and 512hz sonde.
Battery powered Mini Miller / Mini Cleaner
The Mini Miller and Mini Cleaner are now both available in new cordless, battery operated models! With the same features as their original corded versions, now even easier to transport and operate regardless of power outlet location or availability.
Operation time:
- Up to 3 Hours with Standard Battery
- Up to 4 Hours with High output Battery
PICOTE SUPER MIDI MILLER
OVERVIEW
The new Super Midi Miller replaces the older a Midi Miller with powerful upgrades for drain cleaning and reinstatements from DN70/3” to DN150/6”.
The new Midi has an electric safety clutch. It comes with the same powerful control box as Picote’s Maxi Miller and Maxi Power+ have.
In addition to increased efficiency and safety, the Midi now has a 20m range with the option of adding a 10m extension.
Go further in distance, efficiency & safety!
Features include:
- 20m / 70.5ft of 12mm / ½” shaft
- Multi-use machine for heavy descaling, pipe cleaning & reinstatements
- For DN70 – DN150 / 3″ – 6″ pipes.
- Weighs 59kg / 130 lb, 1500 rpm, 1500w output
- Durable electric motor & variable speed control
- Digital control box and electric safety clutch
- Excellent combination of safety, power & portability
PICOTE MAXI MILLER
OVERVIEW
The durable multi-purpose machine.
The Maxi Miller is designed for drain cleaning, root clearing, lateral re-instatements, collapsed liner removal and more, the Picote Maxi Miller is a powerful multi-functional and very durable machine.
Features include:
- 30m/100ft of 12mm / ½” shaft with thick outer casing
- Suitable for drain cleaning & powering the Smart Cutter™, Twister, Collapsed Liner Twister and the Pipe Cutter
- Suitable for the new Smart Spider
- For DN100 – DN200 / 4″ – 8″pipes
- Weighs 95kg / 210 lb
- 1400rpm, 1130w output
- Electric motor & safety clutch
PICOTE MAXI MILLER POWER+
OVERVIEW
The Maxi Miller Power Plus is a new, powerful and efficient multi-use trenchless system from Picote.
It allows the use of Picote’s unique tools in DN150-300 / 6”-12” sewers (also DN70 & 100 / 3” & 4” in straight pipes).
The Miller Power Plus System is designed for faster lateral rein-statements, even higher speed drain cleaning and more efficient collapsed liner removal. The Power Plus provides double the power compared to the regular Maxi Miller (3kw vs. 1.5kw).
Features include:
- 20m/64ft of 18mm / ¾” shaft which can be extended by 10m / 32ft
- Suitable for heavy duty drain cleaning with Picote Original and Cyclone chains
- Fast reinstatements with the Smart Cutter™ and Twister
- Tough descaling with the Smart Spider
- Challenging liner removal with the special Smart Crusher and Smart Sweeper tools
- For DN150 – DN225 / 6″ – 9″pipes
- Can be used in DN100 / 4″ straight pipes
- For descaling/cleaning, can be used in pipes up to DN300/12″
- 3-phase 16 amp 400v / 3.5kw / 1800rpm
- Electric motor and safety clutch.
- Control box can be detached and operated from access point
SHAFT EXTENSIONS & REPLACEMENT SHAFTS
Available as replacement or extension shafts in different lengths for each miller, ranging thickness from 6mm to 18mm. Also available shaft connectors for extending shafts, and Shaft sockets to use the Picote Shaft with a hand drill.
MILLER SPARE PARTS & UPGRADE KITS
For everything on your Picote Miller there is a spare part which you can easily replace by yourself, and upgrade kits, if you want to take your miller one step further, including a foldable handle or even an integrated sewer camera.
SHAFT EXTENSIONS & REPLACEMENT SHAFTS
Available as replacement or extension shafts in different lengths for each miller, ranging thickness from 6mm to 18mm. Also available shaft connectors for extending shafts, and Shaft sockets to use the Picote Shaft with a hand drill.
MILLER SPARE PARTS & UPGRADE KITS
For everything on your Picote Miller there is a spare part which you can easily replace by yourself, and upgrade kits, if you want to take your miller one step further, including a foldable handle or even an integrated sewer camera.
